Zebra Impressora Térmica ZD421 Usb/Ethernet

Descrição

Marca Zebra Modelo ZD4A042-30EE00EZ Especificações - Sistema operacional: Link-OS®
- Resolução: 203 dpi/8 dots per mm
- Memória
512 MB Flash; 256MB SDRAM
64 MB user available non-volatile memory
8 MB user available SDRAM
- Largura máxima de impressão
4.09 in./104 mm for 203 dpi
4.27 in./108 mm for 300 dpi
- Cartucho: 4.09 in./104 mm for 203 and 300 dpi
- Velocidade máxima de impressão
6 in./152 mm per second (203 dpi)
4 in./102 mm per second (300 dpi)
- Sensores de mídia: Sensor móvel de largura total de reflexo/marca preta, sensor de transmissão/hueco de posição múltipla
- Firmware: ZPL II; EPL 2; XML; ZBI; PDF Direct
- Térmica directa: 220,8 mm L x 177,5 mm W x 150,7 mm H
- Rolo de transferência térmica: 267 mm L x 202 mm W x 189 mm H
- Cartucho de transferência térmica: 254 mm L x 202 mm W x 177 mm H
- Peso Térmica Directa: 1,35 kg
- Rolo de Transferência Térmica: 2,05 kg
- Cartucho de Transferência Térmica: 2,3 kg Internet - LAN Ethernet
- USB
- USB Host Características de papel - Label Length
Maximum: 39.0 in./991 mm
Minimum: 0.25 in./6.4 mm
- Media Width
Direct Thermal: 0.585 in./15 mm to 4.25 in./108 mm
Thermal Transfer Roll: 0.585 in./15 mm to 4.41 in./ 112 mm
Thermal Transfer Cartridge: 0.585 in./15 mm to 4.65 in./118 mm
- Media Roll Size
Maximum outer diameter: 5.00 in./127 mm
Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm)
- Média Thickness 0.003 in. (0.08 mm) min.; 0,0075 in. (0.19 mm) max.
- Media Types Roll-fed or fan-fold, die cut or continuou with or without black mark, tag stock, continuou receipt paper, and wristbands
- Ribbon Outside Diameter 2.6 in./66 mm (300 m); 1.34 in./34 mm (74 m)
- Ribbon Standard Length
Roll: 984 ft. (300 m); 243 ft. (74 m)
Cartridge: 243 ft. (74 m)
- Ribbon Ratio
1:4 ribbon to media (300 m)
1:1 ribbon to media (74 m)
- Ribbon Width Roll:
1.33 in./33.8 mm - 4.3 in./109.2 mm
Cartridge: 4.3 in./109.2 mm
- Ribbon Core I.D.
300 meter ribbon 1 in./25.4 mm
74 meter ribbon 0.5 in./12.7 mm Códigos de barras - Bar Code Ratios: 2:1 and 3:1
- 1D Bar Codes: Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13,
UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of- 5,
Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code
- 2D Bar Codes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec
- Fonts and Graphics: 16 residemt expandable ZPL II bitmap fonts, two residemt scalable ZPL fonts,
Five residemt expandable EPL2 fonts, native open-type font support, Unicode compliant.
China units include SimSun simplified Chinese font Data de revisão 31-03-2023 por RTY
