Quiosque / Dispensador de Senhas ZQ-K156 - Ecran 15,6" Intel i5 7300 / DDR4 8GB / SSD 128GB / Impressora 80mm / Audio + Colunas de Som / W11PRO

Descrição

• Dispensador de Senhas
• Opcionals:
• - ID Card
• - Suporte TPA
• Zonerich
• 15.6-Inch Vertical Self-Service Kiosk
• Efficient - Stable - Easy to maintain
• Tailored for modern business and government scenarios
• Large HD touch screen experience
• Equipped with a 15.6-inch high-brightness IPS LCD display with a resolution of up to 1920 × 1080, equipped with capacitive multi-touch, responsive, smooth operation.
• Powerful PC-BOX Configuration
• Built-in high-performance processor.
• 8GB RAM
• 128GB SSD (optional)
• Supports Windows / Linux system.
• High-performance printing unit
• Supports up to:
• 200 mm diameter thermal paper roll
• 80 mm paper width
• Pull-out structure design makes paper replacement easier and improves efficiency.
• With ticket output function, the user can easily pull the voucher.
• Insertion type card reader
• Supports:
• Magnetic stripe cards
• IC cards (ISO 7816)
• Suitable for:
• Payment
• Identity authentication
• Membership cards
• Other applications
• Rear door structure design
• Modular design.
• Mainframe, printer and card reader are separated into independent modules for easier maintenance and upgrades.
• Typical Application Scenarios
• Automatic Ticketing
• Station / Airport automated ticketing
• Administrative kiosks
• Medical self-check-in kiosks
• Product Appearance
• Specification
• Product name
• 15.6" Intelligent Self-service Terminal
• Installation method
• Floor Vertical
• Structural design
• Rear Door Opening Maintenance / Modular Replacement
• Shell material
• Mainframe Sheet Metal + Powder Coating Process
• Whole color
• Standard Gray + Black (Customizable)
• Working temperature
• 0°C ~ 50°C
• Storage temperature
• -20°C ~ 60°C
• Relative humidity
• 10% ~ 90% (Non-condensing)
• Display & Touch
• 15.6" IPS LCD
• High brightness (300–400 cd/m²)
• Resolution: 1920 × 1080
• Contrast ratio: >1000:1
• Capacitive 10-point touch
• System
• CPU
• Intel® Core™ i5-7300U Dual-Core / RK3568
• Memory
• 8GB DDR4 / Android 4G
• Storage
• 128GB SSD / Android 64G
• Operating System
• Windows 10 / 11
• Linux Ubuntu
• Android
• System Interface
• USB: 4
• LAN: 1
• Audio Out
• Optional Wi-Fi module
• Print Unit
• Printing method
• Thermal printing
• Printing width
• 80 mm
• Paper roll support
• Thermal paper rolls up to 200 mm diameter
• Paper change method
• Pull-out paper change for easy operation
• Card Reader Unit
• Type
• Plug-in smart card reader
• Standard
• ISO 7816
• Supports:
• IC Card
• Magnetic Card
• NFC (optional)
• Interface
• USB interface to connect to host computer
• Power Supply Parameters
• Power input
• AC 100V–240V, 50/60Hz
• Power output
• DC 12V / 7A
