MSI Placa-mãe PRO H610M-G DDR4 mATX 1700

Descrição

Marca MSI Modelo 911-7D46-003 Plataforma - mATX (23.6 cm x 20.2 cm) Chipset - Intel® H610 Chipset CPU
Soportados - Aceita processadores Intel Core, Pentium Gold e Celeron de 12a, 13a e 14a geração
- Zócalo do processador LGA1700 Memória - 2 x DDR4, suporta até 64GB
- Soporta 1R 2133/ 2666/ 3200 MHz (por JEDEC e POR)
- Aceita o modo de duplo canal
- Aceita memória sem búfer nem ECC Slots Expansão - 1x PCIe x16 slot (From CPU)
- 1x PCIe x1 slot
- 1x M.2 slot with E-key for PCIe WiFi module only (M2 WIFI1) Gráficos - 1x HDMI 2.1 with HDR port, a maximum resolution of 4K 60Hz 1 2
- 1x VGA port, a maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz1
- 1x DisplayPort 1.4 port, a maximum resolution of 4K 60Hz Portos E/S, Conectores Conectores Internos E/S - 1x Intel® I219V 1Gbps LAN controller
- 1x 24-pin ATX main power
- 1x 8-pin ATX 12V power
- 1x 4-pin CPU fã
- 1x 4-pin system fan
- 1x Front painel áudio
- 2x System painel s
- 1x Chassis Intrusion
- 1x TPM module
- 1x Clear CMOS jumper
Painel E/S Trasero - HDMI
- VGA
- DisplayPort
- Keyboard/Mouse
- USB 3.2 Gen 1 5Gbps Type-A
- LAN port
- Audio connector
- USB 2.0 Outras Características USB
- Intel® H610 Chipset
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back painel, 2 ports available through the internal USB connector)
6x USB 2.0 ports (4 Type-A ports on the back painel(hub-GL850G), 2 ports available through the internal USB 2.0 connector)
Armazenamento
- 4x SATA 6Gb/s ports
Áudio
- Realtek® ALC892/ ALC897 Codec
- 7.1-Channel High Definition Audio
LAN
- 1x Intel® I219V 1Gbps LAN controller
Sistema operacional
- Suporte para Windows 11 64-bit Data Revisão 23-06-2025 por RTY
