MSI Placa-mãe A520M PRO mATX AM4

Descrição

Marca msi Modelo A520M PRO
(911-7D14-011) Plataforma - M-ATX (24.4 cm x 21 cm) Chipset - AMD® A520 chipset CPU
Soportado - Suporte AMD® Ryzen TM 1st, 2nd e 3rd Gen RyzenTM Desktop Processors and AMD RyzenTM 4000 G-Series Desktop Processors Memória - 2 x DDR4 memory slots, até 64GB
Soporta DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
Soporta DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE
- 1DPC 1R max speed 4600 MHz
- 1DPC 2R max speed 3866 MHz
- Dual channel memory architecture
- Soporta non-ECC UDIMM memory
- Soporta ECC UDIMM memory (non-ECC mode)
- Soporta um-buffered memory Slots Expansão - 1 x PCIe x16 slot (PCI E2)
- 2 x PCIe 3.0 x1 slots Gráficos - 1 x VGA
- 1 x HDMI 2.1
- 1 x DisplayPort Portos E/S, Conectores Internos - 1 x 24-pin ATX main power
- 1 x 8-pin ATX 12V power
- 4 x SATA 6Gb/s
- 1 x Serial port
- 1 x M.2 slot (M-Key)
- 1 x USB 3.2 Gen 1 5Gbps
- 2 x USB 2.0
- 1 x 4-pin CPU fã
- 1 x 4-pin system fã
- 1 x Front painel áudio
- 2 x System painel
- 1 x Chassis Intrusion
- 1 x 4-pin RGB LED
- 1 x 3-pin RAINBOW LED
- 1 x TPM module
- 1 x Clear CMOS Externos - 1 x VGA
- 1 x PS / 2 porto combinado
- 2 x USB 2.0
- 1 x DisplayPort
- 1 x LAN
- 1 x HD Audio
- 1 x HDMI
- 4 x USB 3.2 Gen1 Outras Características Armazenamento
- 4 x SATA 6Gb/s ports
- 1 x M.2 slot (Key M)
RAID
- Soporta RAID 0, RAID1 e RAID 10
USB
- 2 x USB 3.2 Gen 1
- 6 x USB 2.0
- 4 x USB 3.2 Gen 1
Rede
- 1 x controlador Realtek® 8111H Gigabit LAN
Áudio
- Códec Realtek® ALC892
- Audio de alta definição de 7.1 canais Montaje
- 6 x buracos de montagem Data Revisão 04-10-2023 por RTY
