ASUS Placa-mãe PRIME B550M-K mATX AM4

Descrição

MarcaAsusModeloPRIME B550M-K
(90MB14V0-M0EAY0)Plataforma- m-ATX (24.4 cm x 24.4 cm)Chipset- AMD® B550 chipsetCPU Soportados- Suporte AMD RyzenTM 3a geração e AMD RyzenTM 3a geração com processador de gráficos RadeonTM com Socket AMD AM4Memória- 3a Gen AMD RyzenTM
4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory *
- 3a Gen AMD RyzenTM com gráficos RadeonTM
4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory *
- Dual Channel Memory Architecture
- ECC Memory (ECC mode)Slots Expansão3rd Gen AMD RyzenTM Processors
- 1 x PCIe 4.0 x16 (x16 mode)
3rd Gen AMD RyzenTM with RadeonTM Graphics Processors
- 1 x PCIe 3.0 x16 (x16 mode)
AMD B550 Chipset
- 2 x PCIe 3.0 x1 Gráficos- 1 x D-Sub
- 1 x DVI- D
- 1 x HDMI 2.1(4K@60HZ)Portos E/S, ConectoresInternos- 1 x CPU Fan
- 2 x Chassis Fan
- 1 x USB 3.2 Gen 1
- 2 x USB 2.0
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)
- 1 x SPI TPM header
- 4 x SATA 6Gb/s
- 1 x S/PDIF out header (s)
- 1 x 24-pin EATX Power
- 1 x 8-pin EATX 12V Power
- 1 x Front painel áudio (AAFP)
- 1 x Clear CMOS jumper(s)
- 1 x System painel
- 1 x COM port header
- 1 x Speaker
Externos- 1 x PS/2 keyboard/mouse combo
- 1 x DVI- D
- 1 x D-Sub
- 1 x HDMI
- 1 x LAN (RJ45)
- 2 x USB 3.2 Gen 2 (teal blue) (2 x Type-A)
- 4 x USB 3.2 Gen 1 (blue) Type-A
- 3 x Audio jack( s)Outras CaracterísticasArmazenamento
- 2 x M.2
- 4 x SATA 6Gb/s
- Soporta Raid 0, 1, 10
USB
- 2 x USB 3.2 Gen 2 (2 x Type-A)
- 4 x USB 3.2 Gen 1 (4 x Type-A)
- 2 x USB 3.2 Gen 1 (2 x Type-A)
- 4 x USB 2.0 (4 x Type-A)
Rede
- Realtek RTL8111H 1Gb Ethernet
- ASUS LANGuard
Áudio
- Realtek ALC887 7.1 Surround Sound High Definition Audio CODECData Revisão14-09-2020 por MSB
